RED V-RAPTOR XL 8K VV – Full-Frame Cinema Camera, PL Mount (V-Lock)

REF: RED-710-0346

35.875 € tax excl.

€43,408.75

tax incl.

Have you seen it cheaper? Ask us for an offer!

8K VV full-frame (40.96 x 21.60 mm, 35.4 MP) sensor
17+ stops of dynamic range
8K up to 120 fps · 4K up to 240 fps · 2K up to 480 fps
REDCODE RAW and Apple ProRes on CFexpress Type B
Mount: interchangeable PL (EF optional) · body: 3.62 kg
internal electronic ND, 2 to 7 stops
Exclusive RED distributor for Spain and Portugal: CATTS warranty and service

Add to wishlist

Reserve

Talk to sales support.

shuffleRelated products

Petición de reserva

Lo sentimos, ha ocurrido un error mientras se mandaba el formulario. Vuelve a intentarlo, si sigue sin funcionar contacta con el comerciante.

Debes aceptar la política de privacidad.

Gracias por tu interés. La petición ha sido enviada. Próximamente nos pondremos en contacto contigo.

Description

V-RAPTOR™ XL 8K VV expands upon the most powerful and advanced RED® camera platform ever. Using RED’s new flagship sensor, V-RAPTOR XL leverages the industry proven V-RAPTOR™ 8K VV sensor inside of a large-scale-production ready XL camera body.

V-RAPTOR XL is designed to support high-end television and motion picture productions as well as any filmmaker who requires an all-in-one solution.

Dual voltage battery support offers compatibility with a wide range of common batteries found on set today, both 14 V batteries and high voltage 26 V V-Lock or Gold Mount options.

12 V and 24 V auxiliary power outputs allows camera assistants to power all the peripherals needed to do their job from one centralized place.

Front facing 3G-SDI and 2-Pin 12 V power, as well as compatibility with the DSMC3™ RED® Touch 7.0” LCD, supports any camera operators viewing preference.

Wireless timecode, genlock, and camera control, as well as four SDI outputs support the DIT, giving them access to everything they need at their cart.

Built-in electronic ND allows cinematographers to precisely select their density in ¼, 1/3, and full stop increments, providing never before seen exposure and depth of field control inside a cinema camera of this level.

V-RAPTOR 8K VV SENSOR INSIDE

Featuring the same groundbreaking multi-format 8K sensor found inside the compact and modular V-RAPTOR body, the V-RAPTOR XL 8K VV has the ability to shoot 8K large format or 6K S35, unlocking the largest lens selection of any comparable camera on the market while allowing shooters the ability to always capture at over 4K.

The sensor also boasts the highest recorded dynamic range and cleanest shadow performance of any RED camera.

In addition, the V-RAPTOR sensor scan time is 2x faster than any previous RED camera and it allows users to capture up to 600 fps at 2K. V-RAPTOR XL will also continue to feature RED’s proprietary REDCODE RAW codec, allowing users to capture 16-bit RAW, and leverage RED’s latest IPP2 workflow and color management.

Features

SENSOR TYPE: V-RAPTOR™ 8K VV 35.4 Megapixel CMOS.

EFFECTIVE PIXELS: 8192 × 4320.

SENSOR SIZE: 40.96 mm x 21.60 mm (Diagonal: 46.31 mm).

DYNAMIC RANGE: 17+ stops.

MOUNT TYPE:

- Integrated RF mount with RF lens support.

- Supports Canon EF lenses via compatible Canon RF to EF mount adapters.

- Accepts other Canon RF mount-based lens adaptors for diverse lens choices.

MAX DATA RATES: Up to 800 MB/s using RED branded or other qualified CFexpress media cards.

REDCODE® RAW MAX FRAME RATES

- 120 fps at 8K 17:9 (8192 x 4320), 150 fps at 8K 2.4:1 (8192 x 3456).

- 140 fps at 7K 17:9 (7168 x 3780), 175 fps at 7K 2.4:1 (7168 x 3024).

- 160 fps at 6K 17:9 (6144 x 3240), 200 fps at 6K 2.4:1 (6144 x 2592).

- 192 fps at 5K 17:9 (5120 x 2700), 240 fps at 5K 2.4:1 (5120 x 2160).

- 240 fps at 4K 17:9 (4096 x 2160), 300 fps at 4K 2.4:1 (4096 x 1728).

- 320 fps at 3K 17:9 (3072 x 1620), 400 fps at 3K 2.4:1 (3072 x 1296).

- 480 fps at 2K 17:9 (2048 x 1080), 600 fps at 2K 2.4:1 (2048 x 864).

AVAILABLE REDCODE® SETTINGS:

- REDCODE HQ, MQ and LQ at 8K 17:9 (8192 x 4320) up to 60 fps.

- REDCODE LQ at 8K 17:9 (8192 x 4320) up to 120 fps.

- REDCODE HQ, MQ and LQ at 6K 17:9 (6144 x 3240) up to 96 fps.

- REDCODE MQ and LQ at 6K 17:9 (6144 x 3240) up to 160 fps.

- REDCODE HQ, MQ and LQ at 4K 17:9 (4096 x 2160) up to 240 fps.

- REDCODE HQ, MQ and LQ at 2K 17:9 (2048 x 1080) up to 480 fps.

REDCODE® RAW ACQUISITION FORMATS:

- 8K 17:9 (8192 x 4320), 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x, 1.5x, 1.3x, 1.25x.

- 7K 17:9 (7168 x 3780), 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x.

- 6K 17:9 (6144 x 3240), 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 1.5x, 1.3x, 1.25x.

- 5K 17:9 (5120 x 2700), 2:1, 2.4:1, 16:9, 1:1.

- 4K 17:9 (4096 x 2160), 2:1, 2.4:1, 16:9, 1:1.

- 3K 17:9 (3072 x 1620), 2:1, 2.4:1, 16:9, 1:1.

- 2K 17:9 (2048 x 1080), 2:1, 2.4:1, 16:9, 1:1.

APPLE PRORES:

- Dedicated recording in ProRes 4444 XQ, ProRes 4444, ProRes 422 HQ, ProRes 422, and ProRes 422 LT with resolutions up to 4K (4096x2160).

- Proxy recording available up to ProRes 422 HQ in 2K (2048 x 1080).

CONSTRUCTION: Aluminum Alloy.

WEIGHT: 4.03 lbs (without body cap and CFexpress card)

DIMENSIONS: 6" x 4.25" x 4.25" (L x W x H).

BATTERY TYPE: Integrated V-Lock battery interface optimized for Micro V-Lock Batteries.

DC POWER INPUT: 11-17V via 6-pin DC-IN.

OPERATING TEMPERATURE: 0°C to 40°C (32°F to 104°F).

STORAGE TEMPERATURE: –20°C to 50°C (–4°F to 122°F).

RELATIVE HUMIDITY: 0% to 85% non-condensing.

COLOR MANAGEMENT:

- Image Processing Pipeline 2 (IPP2).

- Supports 33×33×33 3D LUTs.

- Supports import of CDLs.

AUDIO:

- Integrated dual channel digital mono microphones, uncompressed, 24-bit 48 kHz.

- Integrated dual channel mic/line/+48V input via 5-pin Audio Port, uncompressed, 24-bit 48 kHz.

AUTOFOCUS: Contrast and Phase Detect.

REMOTE CONTROL:

- Wi-Fi for camera control via interchangeable dual band (2.4 GHz/5 GHz) antenna mounted to a female RP-SMA connector.

- Genlock, Timecode-in, GPIO and Ctrl (RS-232) via the integrated 9-pin EXT Port.

- Wired control via USB-C or Gigabit Ethernet (compatible USB-C to Ethernet adapter required) allowing remote camera control, live MJPEG preview video feed and remote media offload.

MONITOR OUTPUTS:

- Integrated dual 12G-SDI with 6G-SDI, 3G-SDI and 1.5G-SDI modes.

- 12G-SDI: Up to 4096 x 2160 4:2:2 for 60p.

- 6G-SDI: Up to 4096 x 2160 4:2:2 for 30p, 25p, 24p.

- 3G-SDI: Up to 2048 x 1080 4:2:2 for 60p.

- 1.5G-SDI: Up to 2048 x 1080 4:2:2 for 30p, 25p, 24p.

- SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio.

MONITOR OPTIONS:

- DSMC3 RED® Touch 7.0” LCD.

- Wireless 1080p live preview video feed via 2.4Ghz/5Ghz Wi-Fi for framing.

- Integrated 2.4" LCD for camera control (no preview video).

RED CONTROL:
