LEITZ ZOOM PL T2.8 - 25-75 mm - MetricLEITZ-11482-002
The Leitz Cine Zoom 25-75mm PL Lens features a PL mount and focus scales marked in feet. This zoom lens has an image circle that covers the VistaVision format, so it will easily cover full-frame sensors.
Featuring a parfocal design and a T2.8 aperture throughout its zoom range, the lens holds focus throughout the zoom and does not ramp exposure as you get to the extremes of the range.
The lens design also reduces the breathing and image shift sometimes encountered while zooming and focusing.
It is color-matched to Leitz primes for seamless intercutting between the lenses.
The 15-bladed iris produces attractive bokeh in out-of-focus areas, with naturalistic-looking round out-of-focus highlights. The focus, iris, and zoom control rings have cine-style 0.8 MOD gears, and the focus ring features approximately 270 degrees of rotation.
The 25 to 75mm zoom features a 114mm front diameter common to many cinema-style matte boxes.
The lens has a built-in support foot with a 3/8"-16 threaded mounting hole that helps support the lens with the aid of an optional 3/8"-16 rod-mounted lens support (not included).
- Focal Length Ratio: 3
- Aperture: T2.8
- Image Circle: 46.5 mm
- Close Focus: 3’ / 0.91 m
- Horizontal angle of view “Full Frame” 36 x 24 mm: at 25 mm
- Horizontal angle of view “Full Frame” 36 x 24 mm: at 50 mm
- Horizontal angle of view “Full Frame” 36 x 24 mm: at 75 mm
- Horizontal angle of view “Super 35” 24.9 x 18.7 mm: at 25 mm
- Horizontal angle of view “Super 35” 24.9 x 18.7 mm: at 50 mm
- Horizontal angle of view “Super 35” 24.9 x 18.7 mm: at 75 mm
- Weight: 8.2 lb / 3.7 kg
- Length: 10.5" / 266.6 mm
- Entrance Pupil (mm): at 25 mm, at 50 mm and at 75 mm
- Front Diameter: 114 mm
- Front Filter: M 112 x 1.5 mm screw-in
- Rear Filter: Via net holder. With LPL Adapter for both, with PL Adapter only with 55-125 mm
- Matched Focus/Iris Ring Locations: Both
- Focus Rotation: 270°
- Iris Rotation: 54°
- Focus Scales: Turnable scale, easy change from imperial to metric
- Iris Shape: Circular through all stops
- Color Matching: Matched with LEITZ PRIME lenses
1x LEITZ ZOOM PL T2.8 - 25-75 mm - Metric
